XM-10 17" RTX 4080 I9 14900HX 4K
CPU
14th Gen Intel Core i9-14900HX ( Max Turbo boost up to 5.80 GHz ), 8 P-cores & 16 E-cores / 32 thread, 36MB Smart Cache
Chipset Intel HM770 Express Chipset
Display
17.3” UHD (3840x2160) 144Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Memory
Supports Dual Channel DDR5
Two 262 pins SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Video Controller
NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support up to 4 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and Thunderbolt 4 x1
NVIDIA GeForce RTX 4080 Laptop GPU
- 12GB GDDR6 Video RAM
- NVIDIA Ada Lovelace Architecture
- Microsoft DirectX 12
- GeForce CUDA technology
- Support PCIe Gen4
- Dynamic Boost 2.0
Intel UHD Graphics (Integrated in 13th Gen Core i9 CPU)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Maximum TGP: 175 W (including 25W Dynamic Boost 2.0)
Storage
Three M.2 2280 SSD PCIe Gen 4x4 interface
Sound System
High Definition audio interface
S/PDIF digital output
Built-in Array Microphone
Built-in two speakers
Sound Blaster Studio Pro Driver
Audio Amplifier on headphone output
Keyboard Multi languages LED Per Key full color illuminated full size keyboard with numeric pad
Pointing Device Built in Click pad with Microsoft PTP multi-gesture and scrolling function
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4
1 Thunderbolt 4 combo Port with Power Delivery DC in (Type C)
1 Thunderbolt 4 Port (Type C)
2 USB 3.2 Gen 2 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Slots
Four M.2 Card Slots,
- 1st for WLAN Combo M.2 2230 Card with PCIe / USB / CNVi interface (E key)
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
- 4th for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
Communication
Built-in Killer 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
(Factory Option) Killer Dual Band Wireless-AX 1650X + Bluetooth, M.2 interface
Other Features
Metal top, palm rest and bottom case
Built-in 2.0M FHD Hello Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Intel Dynamic Tuning Technology
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Killer DoubleShot Pro with Killer Wireless Module
Power
Full Range 330W AC Adapter, AC-in 100~240V, 50~60Hz, DC output 19.5V, 16.92A
Embedded 8 cells Polymer battery pack 99WH
Security
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)
TPM 2.0
OS Support
Windows 11 (64-bit)
Certificate Windows 11 (64-bit) Logo
HDMI Logo
Dimension
15.59” (w) x 10.95” (d) x 0.98” (h)
7.25 lbs. including Bare bone and 99WH Battery Pack
XM-10 17" RTX 4090 I9 14900HX 4K BACKORDER ETA EARLY OCT
CPU
14th Gen Intel Core i9-14900HX ( Max Turbo boost up to 5.80 GHz ), 8 P-cores & 16 E-cores / 32 thread, 36MB Smart Cache
Chipset Intel HM770 Express Chipset
Display
17.3” UHD (3840x2160) 144Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Memory
Supports Dual Channel DDR5
Two 262 pins SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Video Controller
NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support up to 4 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and Thunderbolt 4 x1
NVIDIA GeForce RTX 4090 Laptop GPU
- 16GB GDDR6 Video RAM
- NVIDIA Ada Lovelace Architecture
- Microsoft DirectX 12
- GeForce CUDA technology
- Support PCIe Gen4
- Dynamic Boost 2.0
Intel UHD Graphics (Integrated in 13th Gen Core i9 CPU)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Storage
Three M.2 2280 SSD PCIe Gen 4x4 interface
Sound System
High Definition audio interface
S/PDIF digital output
Built-in Array Microphone
Built-in two speakers
Sound Blaster Studio Pro Driver
Audio Amplifier on headphone output
Keyboard Multi languages LED Per Key full color illuminated full size keyboard with numeric pad
Pointing Device Built in Click pad with Microsoft PTP multi-gesture and scrolling function
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4
1 Thunderbolt 4 combo Port with Power Delivery DC in (Type C)
1 Thunderbolt 4 Port (Type C)
2 USB 3.2 Gen 2 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Slots
Four M.2 Card Slots,
- 1st for WLAN Combo M.2 2230 Card with PCIe / USB / CNVi interface (E key)
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
- 4th for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
Communication
Built-in Killer 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
(Factory Option) Killer Dual Band Wireless-AX 1650X + Bluetooth, M.2 interface
Other Features
Metal top, palm rest and bottom case
Built-in 2.0M FHD Hello Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Intel Dynamic Tuning Technology
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Killer DoubleShot Pro with Killer Wireless Module
Power
Full Range 330W AC Adapter, AC-in 100~240V, 50~60Hz, DC output 19.5V, 16.92A
Embedded 8 cells Polymer battery pack 99WH
Security
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)
TPM 2.0
OS Support
Windows 11 (64-bit)
Certificate Windows 11 (64-bit) Logo
HDMI Logo
Dimension
15.59” (w) x 10.95” (d) x 0.98” (h)
7.25 lbs. including Bare bone and 99WH Battery Pack
