XM-5 15" RTX 4050 RYZEN 7 8845HS
Processor
AMD Ryzen 7 8845HS processor ( 3.8 GHz, Max Boost Up to 5.1 GHz ), 8 cores / 16 threads, 24MB Cache
Memory
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 up to 5600MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module.
Display
15.6” Full HD (1920x1080) 144Hz, Wide View Angle, 72% NTSC, Matte Finished
Graphics
Processor Switchable GPU by Microsoft Hybrid Graphics - NVIDIA GeForce RTX 4050 GPU / AMD Radeon Graphics
Support 3 active displays
NVIDIA GeForce RTX 4050 Laptop GPU
- 6GB GDDR6 Video RAM
- Microsoft DirectX 12
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 105 W (including 25W Dynamic Boost 2.0)
AMD Radeon 780M Graphics (Integrated in Ryzen 7 Processor)
- HDR Support
- FidelityFX Super Resolution (FSR)
- Microsoft DirectX 12 compatible
Storage
Two M.2 2280 SSD PCIe Gen 4x4 interface
Audio System
High Definition audio interface
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio+
Pointing Device
Built in Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
I/O Ports
1 HDMI output Port (with HDCP)
1 DisplayPort 1.4 over USB 3.2 Gen 2 Port (Type C)
1 USB 3.2 Gen 2 Port (Type C) with Power Delivery DC-in
1 USB 3.2 Gen 2 Port (Type A)
1 USB 3.2 Gen 1 Port (Type A)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000Mbps)
Slots
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
Communication
Built-in Gigabit Ethernet LAN
Intel Dual Band Wireless-Wi-Fi 6E AX210 + Bluetooth, M.2 interface
Security
Security (Kensington Type) Lock Slot
FTPM for system without Hardware TPM
Power System
Built in 4 cells Polymer battery pack 53.35WH
Full Range AC-in 100~240V, 50~60Hz, 180W AC Adapter, DC output 20V, 9A
OS Support
Windows 11 (64-bit)
Certificate
Windows 11 (64-bit) Logo
HDMI Logo
Physical Characteristic
5.06 LBs including bare bone and Battery Pack
14.21" (w) x 9.78" (d) x 0.98" (h)
Other Features
Built-in 1.0M HD Video Camera
FlexiCharger
Virtual Reality ready
Specifications are subject to change without notice
XM-5 15" RTX 4060 RYZEN 7 8845HS
Processor
AMD Ryzen 7 8845HS processor ( 3.8 GHz, Max Boost Up to 5.1 GHz ), 8 cores / 16 threads, 24MB Cache
Memory
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 up to 5600MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module.
Display
15.6” Full HD (1920x1080) 144Hz, Wide View Angle, 72% NTSC, Matte Finished
Graphics
Processor Switchable GPU by Microsoft Hybrid Graphics - NVIDIA GeForce RTX 4050 GPU / AMD Radeon Graphics
Support 3 active displays
NVIDIA GeForce RTX 4050 Laptop GPU
- 6GB GDDR6 Video RAM
- Microsoft DirectX 12
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 105 W (including 25W Dynamic Boost 2.0)
AMD Radeon 780M Graphics (Integrated in Ryzen 7 Processor)
- HDR Support
- FidelityFX Super Resolution (FSR)
- Microsoft DirectX 12 compatible
Storage
Two M.2 2280 SSD PCIe Gen 4x4 interface
Audio System
High Definition audio interface
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio+
Pointing Device
Built in Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
I/O Ports
1 HDMI output Port (with HDCP)
1 DisplayPort 1.4 over USB 3.2 Gen 2 Port (Type C)
1 USB 3.2 Gen 2 Port (Type C) with Power Delivery DC-in
1 USB 3.2 Gen 2 Port (Type A)
1 USB 3.2 Gen 1 Port (Type A)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000Mbps)
Slots
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
Communication
Built-in Gigabit Ethernet LAN
Intel Dual Band Wireless-Wi-Fi 6E AX210 + Bluetooth, M.2 interface
Security
Security (Kensington Type) Lock Slot
FTPM for system without Hardware TPM
Power System
Built in 4 cells Polymer battery pack 53.35WH
Full Range AC-in 100~240V, 50~60Hz, 180W AC Adapter, DC output 20V, 9A
OS Support
Windows 11 (64-bit)
Certificate
Windows 11 (64-bit) Logo
HDMI Logo
Physical Characteristic
5.06 LBs including bare bone and Battery Pack
14.21" (w) x 9.78" (d) x 0.98" (h)
Other Features
Built-in 1.0M HD Video Camera
FlexiCharger
Virtual Reality ready
Specifications are subject to change without notice
